Gurit Corecell M100 | 10mm

Manufacturer Brand Image
SKU: M10010PHS



Sheet Dimensions: 1130mm x 2275mm (2.57m2)

Other weights and finishes available, please call our office for more information

  • High performance foam, ideal for marine applications
  • High chemical resistance
  • Low resin absorption
  • High temperature processing (prepreg compatible)
  • Good compressive strength and stiffness
  • DNVGL, RINA, BV, Lloyds and ABS certification
  • High shear strength & elongation

Gurit® Corecell™ M is a structural foam core material using a SAN polymer base featuring high toughness and impact resistant characteristics. It offers very reliable processing without outgassing for high quality parts. Gurit® Corecell™ M is the newest addition to the Gurit® Corecell™ range and shares the benefits of SAN chemistry common to all Gurit® Corecell™ products.

Typical Applications

Gurit® Corecell™ M has been developed to deliver one product for all marine applications. It provides a combination of high shear strength with low density, high elongation, high temperature resistance and low resin uptake. Gurit® Corecell™ M is the perfect choice whether your application is slamming area or superstructure, hull or deck, using hand lamination, infusion or prepreg.

Basic information

  • Sheet size - 1130 mm x 2275 mm
  • Edge marking - Yellow / Black
  • Available thickness - 3 mm - 48 mm

Finishing options

  • PL - Plain
  • PH - Pinholed
  • CS - Scrim Backed
  • DC - Double Cut
  • VIC - Infusion Cut
  • VIC + PH - Infusion Cut with pinholes

For full explanation structural properties and  finishing options see the core guide and data sheet in technical documents or talk to your technical representative
